主要用途:

該設備主要用于大輸液生產過程中對玻璃瓶的清洗，能自動完成絞龍進瓶、撥輪交接瓶至機械手夾瓶頸翻轉180°、外噴洗、內沖洗、外噴洗到瓶翻轉180°撥輪交接出瓶的全套生產過程。

Main Applications:

This machine is mainly used in washing glass bottles during the production of infusion. It can automatically complete the whole process of auger’s entering into the bottle; bottleneck’s revolving 180° from trackwheel folder to manipulator holding, external jetting, internal washing, and overturning the trackwheel 180° to handover the bottles.

性能特點:

• 采用四水二氣六工位的獨特洗瓶方式(可根據用戶自行調整洗瓶次數);
• 機械手夾持瓶頸翻轉180°定位沖洗，對中準確，洗瓶合格率高;
• 更換規格簡單、方便，只需更換絞龍、進出瓶撥輪及微調欄柵即可，機械手不需更換即可多種規格生產;
• 沖洗后的注射用水進入隨機配帶的循環水箱供循環水洗用水，節約能源;
• 循環水洗、注射用水洗，潔凈空氣氣洗都使用獨立的專用管道，不存在交叉污染。

Performance Characteristics:

• A unique washing way of four water- two gas- six stations is adopted (can be adjusted according to the number of washing).
• The manipulator can hold the bottleneck to revolve 180 ° and to position the washing, which improves accuracy and qualification rate.
• It is simple and convenient to change the standard, which only need to replace the auger and trackwheel or fine-tune the barrier. Multi standard production can be done without changing the manipulator.
• The washed injection water enters into random matched cyclic water tank and can be used for cyclic washing, so it can promote energy conservation.
• Cyclic washing, injection water washing, and clean air washing use separate dedicated aqueducts without cross contamination.

主要技術參數:

• 適用容量規格：50ml-500ml
• 洗瓶頭數：32頭(40頭、50頭)
• 生產能力：150b/min(200 b/min、300b/min)
• 耗水量：～0.2MPa 2m3/h
• 耗氣量：～0.5MPa 80m3/h
• 電機功率：2.2Kw 水泵功率：1.5Kw 380V 50Hz
• 總重量：1400Kg(1800Kg、2200Kg)
• 外形尺寸：1750×1950×1450(mm)、2220×2400×1450(mm)、2540×2690×1450(mm)

Main Technical Specifications:

• Applicable volume: 50ml-500ml
• Washing heads: 32(40, 50)
• Production capacity: 150b/min(200 b/min、300b/min)
• Water consumption: ～0.2MPa 2m3/h
• Air consumption: ～0.5MPa 80m3/h
• Motor power: 2.2Kw Pump power: 1.5Kw 380V 50Hz
• Total weight: 1400Kg(1800Kg、2200Kg)
• Dimensions: 1750×1950×1450(mm)、2220×2400×1450(mm)、2540×2690×1450(mm)
