GZB20/1000(S)系列高速貼簽機
主要用途:
Main purpose:
本機為雙面真空轉鼓直線式貼標機,適用于醫藥、食品、化工、輕工等行業中產品包裝紙箱雙面貼標簽,全機可自動完成輸紙箱、涂漿、遞簽、取簽、貼簽等工序。
This machine is the double-side vacuum rotary chamber line mark sticker and is suitable for the doubles-side label sticking of the product packing box in pharmacy, food, chemistry and light industry. The whole machine can automatically complete paper box conveying, slurry painting, label feed, label taking and label sticking.
主要技術參數:
Main technical parameters:
- 生產能力:12-30箱/min
- Productivity:12-30 box/min
- 清洗/灌裝/旋蓋頭數:32/32/16
- Cleaning/filling/capping header number:32/32/16
- 電機功率:1.62Kw 380V 50Hz
- Motor power:1.62Kw 380V 50Hz
- 真空泵功率:0.37Kw 380V 50Hz
- Power of vacuum pump:0.37Kw 380V 50Hz
- 吸氣速率:20m3/h
- Air suction rate:20m3/h
- 紙箱寬度尺寸:240∽450mm
- Width of paper box:240∽450mm
- 標簽規格 :長(50-200)×寬(30-100)=155×85
- Label specification:Length (50-200) x width (30-100)= 155x85
- 主電機功率:4.0Kw 380V 50Hz
- Power of main motor:4.0Kw 380V 50Hz
- 整機重量:960Kg
- Weight of whole machine:960Kg
- 外形尺寸:1650×2000×900(mm)
- Dimension:1650×2000×900(mm)
